FR600F
Reliable
Weichai high-end H platform engine with a lifespan of up to 30,000 hours, Weichai Linde powertrain with a 5-year or 10,000-hour warranty, large cross-section three-stage boom, forged axle seat, double support rollers, "U" shaped plate frame, more reliable.
Efficient
Weichai + Linde hydraulic powertrain technology, self-identifying working condition power allocation system, overall work efficiency improved by 10% compared to the E series, and fuel efficiency increased by more than 15%.
Comfortable
New ventilation duct cab, air suspension seat, Lovol's new intelligent control system, intelligent vehicle control, intelligent insurance, onboard PAD, more comfortable operation.
| Item | Unit | Parameter |
| Operating Weight | kg | 58000 |
| Bucket Capacity | m³ | 3.2 |
| Rated Power | kW | 316 |
| Emissions | - | Stage III |
| Transportation Dimensions(L*W*H) | mm | 12100*3490*3950 |
| Max.Digging Radius | mm | 11544 |
| Max.Digging Height | mm | 10812 |
| Max.Digging Depth | mm | 7152 |
| Max.Unloading Height | mm | 7365 |
| Bucket Digging Force | kN | 320 |
| Stick Digging Force | kN | |
| Track Width | mm | 600 |
